KILOVIEW E1-NDI

KILOVIEW E1-NDI

Kiloview E1 NDI video encoder is the fastest, easiest, and best way to get video into IP workflows. it delivers the groundbreaking benefits of NDI®, NewTek’s innovative Network Device Interface techno

Standaard levertijd

op voorraad

€ 350,00
excl. btw
€ 423,50
incl. btw
Prijs per stuk



Aantal:
Bestellen
Op verlanglijst


Heeft u een vraag over dit product?

Stel ons uw vraag

NDI® OUTPUT, NDI® VIRTUAL INPUT
Deliver any digital video source to the network in full HD, with high-efficiency NDI® output via NDI|HX and native support for resolutions up to 1080p. Designate E1 as the video input source in popular desktop video applications like Google Hangouts, GoToMeeting, Skype, Skype for Business, WebEx, Zoom, and more using the free NDI® Virtual Input* tool. (* NDI Virtual Input included with the free NewTek NDI Tools download.)

SRT SUPPORTED
SRT supported to ensure secure and reliable transmission.

WEB-BASED INTERFACE
Monitor video, manage login credentials, access recording controls and configure audio, video, and network settings from any supported Web browser on any compatible networked device.

NETWORK VISIBILITY
Access devices connected to other networks via IP address and make them visible within your production environment using NDI Access Manager.

HIGH BANDWIDTH ADAPTABILITY
Achieve low bit rate encoding and ensure high definition image quality, 1Mbps@720p, 1.5Mbps@1080p can get high quality video; Kiloview advanced video buffer technology and forward error correction technology ensure video encoding delay ≤ 67ms and no stuck; It supports up to 1080p60Hz video format, the resolution of output format can be customized.

STRONG FLEXIBILITY TO SUPPORT SECONDARY DEVELOPMENT
Open API programming, SDK provided for second development; Customization service is available based on client’s needs.

SUPPORT ALL LIVE BROADCAST PLATFORMS
Support RTMP/HLS/SRT/TS streaming media protocols for live broadcast, With its built-in KILOVIEW ® SUNSHINE streaming media server engine, 20 to 50 concurrent access simultaneously is supported; Dual streams output supported and can be pushed to different live broadcasting platforms simultaneously, main stream encoding up to 1080p60Hz, sub stream encoding support 540p 60Hz.

SUPPORTS ONVIF 1.1/2.0: EASY ACCESS TO SECURITY PROTECTION SYSTEM /NVR SYSTEM.
FEATURES:
SDI to NDI Wired HD Video Encoder
Low latency( ≤ 67)
NDI|HX supported
SDI loop through
Support for SRT and Onvif
7x24h working mode
Low bitrate but quality image transmission
Low power consumption (<4w)

encoder eigenschappen
Video input HD/3G-SDI Video loopout HD/3G-SDI Analog audio input 3.5mm Analog audio output 3.5mm USB interface 2*USB 2.0 Type-A; 1*USB 2.0 Mini-USB Micro SD Micro SD/TF Card Video resolution 1080p23.98/24/25/29.97/30Hz 1080p50/59.94/60Hz 1080i50/59.94/60Hz 720p23.98/24/25/29.97/30Hz 720p50/59.94/60Hz, 576i, 480i 720*480(NTSC),720*576(PAL) Transmission mode Wired/Ethernet Video Encoding H.264/AVC High profile Audio encoding AAC/G.711 Encoding latency ≤67ms Streaming media protocols RTMP/RTMPS/HLS/TS over UDP/RTP/RTSP SRT Management Android App or Web Power DC 12V 1A Operating temperature -4°F to 160°F /-20℃ to 6℃ Dimensions 4.9 x 3.5 x 1.125″/125*89*28mm Weight 13.4oz /380g
